主页 > 产品中心 > Bussmann/巴斯曼 > 贴片保险丝 >
|
Catalog Number |
Amp Rating |
Alpha Marking |
Voltage Rating Vdc |
Interrupting Rating (amps) |
Typical Resistance (Ω)2 |
Typical Melt I2t3 |
Typical Voltage Drop (V) |
Typical Power Loss (W) |
| CC06H1A | 1 | B | 32 | 50 | 0.225 | 0.02 | 0.295 | 0.30 |
| CC06H1.5A | 1.5 | H | 32 | 50 | 0.122 | 0.07 | 0.220 | 0.33 |
| CC06H2A | 2 | K | 32 | 50 | 0.061 | 0.20 | 0.160 | 0.32 |
| CC06H2.5A | 2.5 | L | 32 | 50 | 0.045 | 0.25 | 0.145 | 0.36 |
| CC06H3A | 3 | O | 32 | 50 | 0.027 | 0.30 | 0.110 | 0.33 |
| CC06H3.5A | 3.5 | R | 32 | 50 | 0.021 | 0.60 | 0.100 | 0.35 |
| CC06H4A | 4 | S | 32 | 50 | 0.018 | 1 | 0.100 | 0.40 |
| CC06H5A | 5 | T | 32 | 50 | 0.013 | 2 | 0.088 | 0.44 |
