Part Number |
Rated Current (A) |
Max |
Interrupting Rating |
Nominal Cold Resistance (ohms） |
Nominal Melting I2t(A2sec) |
| JFC2410-0500TS | 0.50 | 250V | 50A@250V | 0.7000 | 0.240 |
| JFC2410-0750TS | 0.75 | 0.3600 | 0.904 | ||
| JFC2410-1100TS | 1.00 | 0.2250 | 1.98 | ||
| JFC2410-1150TS | 1.50 | 0.0930 | 3.65 | ||
| JFC2410-1200TS | 2.0 | 0.0325 | 8.20 | ||
| JFC2410-1250TS | 2.50 | 0.0450 | 15.0 | ||
| JFC2410-1300TS | 3.00 | 0.0340 | 20.16 | ||
| JFC2410-1350TS | 3.50 | 0.0224 | 26.53 | ||
| JFC2410-1400TS | 4.00 | 0.0186 | 34.40 | ||
| JFC2410-1500TS | 5.00 | 0.0136 | 53.72 | ||
| JFC2410-1600TS | 6.00 | 0.0123 | 84.58 | ||
| JFC2410-1630TS | 6.30 | 0.0115 | 95.32 | ||
| JFC2410-1700TS | 7.00 | 0.0105 | 123.83 | ||
| JFC2410-1800TS | 8.00 | 35A@250V | 0.0088 | 137.34 | |
| JFC2410-2100TS | 10.0 | 0.0073 | 187.45 | ||
| JFC2410-2120TS | 12.0 | 0.0061 | 260.46 | ||
| JFC2410-2150TS | 15.0 | 0.0038 | 320.65 |
