Part No.
|
Rated
Voltage DC |
Rated
Current (A) |
Breaking
Capacity |
Typical Cold.
Resistance (mOhms)2 |
Typical
Voltage Drop (mV) |
Typical
Pre-Arcing I2t(A2Sec) |
Aplha
Marking |
|
JFC1206-0250FS
|
72V
|
0.250
|
50A
|
3608
|
1407
|
0.0004
|
.25
|
|
JFC1206-0375FS
|
0.375
|
1882
|
718
|
0.0008
|
E
|
||
|
JFC1206-0500FS
|
0.500
|
1028
|
650
|
0.0022
|
0.5
|
||
|
JFC1206-0750FS
|
0.750
|
601
|
616
|
0.0057
|
.75
|
||
|
JFC1206-1100FS
|
1.000
|
490
|
510
|
0.1
|
H
|
||
|
JFC1206-1125FS
|
1.250
|
165
|
184
|
0.021
|
▲
|
||
|
JFC1206-1150FS
|
1.500
|
240
|
367
|
0.15
|
K
|
||
|
JFC1206-1200FS
|
2.000
|
144
|
316
|
0.41
|
N
|
||
|
JFC1206-1250FS
|
2.500
|
86
|
240
|
0.65
|
O
|
||
|
JFC1206-1300FS
|
3.000
|
53
|
187
|
1.39
|
P
|
||
|
JFC1206-1350FS
|
3.500
|
40
|
180
|
1.68
|
R
|
||
|
JFC1206-1400FS
|
4.000
|
35
|
173
|
1.73
|
S
|
||
|
JFC1206-1450FS
|
4.500
|
27
|
164
|
2.62
|
X
|
||
|
JFC1206-1500FS
|
32V
|
5.00
|
22
|
141
|
2.89
|
T
|
|
|
JFC1206-1650FS
|
6.500
|
16
|
140
|
3.4
|
6.5
|
||
|
JFC1206-1700FS
|
24V
|
7.000
|
12
|
140
|
5.68
|
7
|
|
|
JFC1206-1800FS
|
8.000
|
150A
|
10
|
123
|
6.8
|
M
|
|
|
JFC1206-2100FS
|
10.00
|
4.4
|
59
|
2.16
|
U
|
||
|
JFC1206-2120FS
|
12.00
|
3.8
|
67
|
7.11
|
12
|
||
|
JFC1206-2150FS
|
15.00
|
150A
|
2.9
|
66
|
23.89
|
15
|
|
|
JFC1206-2200FS
|
20.00
|
200A
|
1.6
|
60
|
47.17
|
20
|
|
|
JFC1206-2250FS
|
25.00
|
250A
|
1.4
|
57
|
32
|
25
|
|
|
JFC1206-2300FS
|
30.00
|
300A
|
1
|
68
|
43
|
30
|
