Model
|
Vmax
(Vdc) |
Imax
(A) |
Ihold
@25℃ (A) |
Itrip
@25℃ (A) |
Pd
typ. (W) |
Maximum Time
To Trip |
Resistance
|
||
|
Current
(A) |
Time
(Sec.) |
Rimin
(Ω) |
R1max
(Ω) |
||||||
|
ASMD1812-010
|
30.0
|
100
|
0.10
|
0.30
|
0.8
|
0.5
|
1.50
|
0.750
|
15.000
|
|
ASMD1812-014
|
60.0
|
100
|
0.14
|
0.34
|
0.8
|
1.5
|
0.15
|
0.650
|
6.000
|
|
ASMD1812-020
|
30.0
|
100
|
0.20
|
0.40
|
0.8
|
8.0
|
0.02
|
0.350
|
5.000
|
|
ASMD1812-030
|
30.0
|
100
|
0.30
|
0.60
|
0.8
|
8.0
|
0.025
|
0.300
|
4.00
|
|
ASMD1812-035/30
|
30.0
|
100
|
0.35
|
0.60
|
0.8
|
8.0
|
0.10
|
0.250
|
3.000
|
|
ASMD1812-050
|
15.0
|
100
|
0.50
|
1.00
|
0.8
|
8.0
|
0.15
|
0.150
|
1.000
|
|
ASMD1812-050/30
|
30.0
|
100
|
0.50
|
1.00
|
0.8
|
8.0
|
0.15
|
0.150
|
1.000
|
|
ASMD1812-050/33
|
33.0
|
100
|
0.50
|
1.00
|
0.8
|
8.0
|
0.15
|
0.150
|
1.000
|
|
ASMD1812-050/60
|
60.0
|
100
|
0.50
|
1.00
|
0.8
|
8.0
|
0.15
|
0.150
|
1.400
|
|
ASMD1812-075
|
13.2
|
100
|
0.75
|
1.50
|
0.8
|
8.0
|
0.20
|
0.090
|
0.450
|
|
ASMD1812-075/16
|
16.0
|
100
|
0.75
|
1.50
|
0.8
|
8.0
|
0.20
|
0.090
|
0.450
|
|
ASMD1812-075/24
|
24.0
|
100
|
0.75
|
1.50
|
0.8
|
8.0
|
0.20
|
0.090
|
0.450
|
|
ASMD1812-075/33
|
33.0
|
100
|
0.75
|
1.50
|
0.8
|
8.0
|
0.20
|
0.090
|
0.450
|
|
ASMD1812-110
|
8.0
|
100
|
1.10
|
2.20
|
0.8
|
8.0
|
0.30
|
0.050
|
0.250
|
|
ASMD1812-110/16
|
16.0
|
100
|
1.10
|
2.20
|
0.8
|
8.0
|
0.30
|
0.050
|
0.250
|
|
ASMD1812-110/24
|
24.0
|
100
|
1.10
|
2.20
|
0.8
|
8.0
|
0.30
|
0.050
|
0.250
|
|
ASMD1812-110/33
|
33.0
|
100
|
1.10
|
2.20
|
0.8
|
8.0
|
0.30
|
0.050
|
0.250
|
|
ASMD1812-125
|
16.0
|
100
|
1.25
|
2.50
|
0.8
|
8.0
|
0.40
|
0.050
|
0.140
|
|
ASMD1812-150
|
8.0
|
100
|
1.50
|
3.00
|
0.8
|
8.0
|
0.50
|
0.040
|
0.160
|
|
ASMD1812-150/16
|
12.0
|
100
|
1.50
|
3.00
|
0.8
|
8.0
|
0.50
|
0.040
|
0.160
|
|
ASMD1812-160
|
8.0
|
100
|
1.60
|
2.80
|
0.8
|
8.0
|
1.00
|
0.030
|
0.130
|
|
ASMD1812-200
|
8.0
|
100
|
2.00
|
4.00
|
0.8
|
8.0
|
2.00
|
0.020
|
0.100
|
|
ASMD1812-260
|
8.0
|
100
|
2.60
|
5.00
|
0.8
|
8.0
|
2.50
|
0.015
|
0.050
|
|
ASMD1812-260/16
|
16.0
|
100
|
2.60
|
5.00
|
0.8
|
8.0
|
2.50
|
0.015
|
0.050
|
|
ASMD1812-300
|
8.0
|
100
|
3.00
|
5.00
|
0.8
|
8.0
|
4.00
|
0.012
|
0.040
|
|
ASMD1812-350
|
6.0
|
100
|
3.50
|
6.00
|
2.0
|
10.0
|
4.00
|
0.008
|
0.030
|
Vmax=元件在額定電流下能承受的最大電壓.
Imax=元件在額定電壓下能承受的最大電流.
Ihold=在25℃靜止空氣環境中,產品不動作的最大電流.
Itrip=在25℃靜止空氣環境中,最小動作電流.
Pd=在25℃靜止空氣環境中,產品動作狀態下的消耗功率.
Rimin/max=25℃溫度條件下的初始阻值(焊接前).
R1max=25℃溫度條件下,焊接一小時後的最大阻值.
注意:超出指定額定值的操作，可能會導致損傷和可能產生電弧和火焰.
