型號 |
工作電壓 |
最大電流 |
保持電流 |
跳閘電流 |
消耗功率 |
最大電流跳閘時間 |
電阻範圍 |
|||
|
V max |
Imax |
I hold |
I trip |
Pd |
電流 |
時間 |
Rimin |
Rimax |
R1max |
|
|
(Vdc) |
(A) |
(A) |
(A) |
(W) |
(A) |
(Sec) |
(W) |
(W) |
(W) |
|
|
A16-090 |
16 |
40 |
0.90 |
1.80 |
0.60 |
8.00 |
1.2 |
0.070 |
0.1200 |
0.180 |
|
A16-110 |
16 |
40 |
1.10 |
2.20 |
0.70 |
8.00 |
2.3 |
0.050 |
0.0950 |
0.140 |
|
A16-135 |
16 |
40 |
1.35 |
2.70 |
0.80 |
8.00 |
4.5 |
0.040 |
0.0740 |
0.120 |
|
A16-160 |
16 |
40 |
1.60 |
3.20 |
0.90 |
8.00 |
9.0 |
0.030 |
0.0610 |
0.110 |
|
A16-185 |
16 |
40 |
1.85 |
3.70 |
1.00 |
8.00 |
10.0 |
0.030 |
0.0510 |
0.090 |
|
A16-200 |
16 |
40 |
2.00 |
4.00 |
1.10 |
8.00 |
10.0 |
0.030 |
0.0350 |
0.080 |
|
A16-250 |
16 |
40 |
2.50 |
5.00 |
1.20 |
12.50 |
5.0 |
0.020 |
0.0350 |
0.060 |
|
A16-300 |
16 |
40 |
3.00 |
5.10 |
2.30 |
15.00 |
1.0 |
0.034 |
0.0650 |
0.105 |
|
A16-400 |
16 |
40 |
4.00 |
6.80 |
2.40 |
20.00 |
1.7 |
0.020 |
0.0390 |
0.063 |
|
A16-500 |
16 |
40 |
5.00 |
8.50 |
2.60 |
25.00 |
2.0 |
0.014 |
0.0230 |
0.044 |
|
A16-600 |
16 |
40 |
6.00 |
10.20 |
2.80 |
30.00 |
3.3 |
0.009 |
0.0190 |
0.030 |
|
A16-700 |
16 |
40 |
7.00 |
11.90 |
3.00 |
35.00 |
3.5 |
0.006 |
0.0130 |
0.021 |
|
A16-800 |
16 |
40 |
8.00 |
13.60 |
3.00 |
40.00 |
5.0 |
0.005 |
0.0110 |
0.018 |
|
A16-900 |
16 |
40 |
9.00 |
15.30 |
3.30 |
45.00 |
5.5 |
0.004 |
0.0092 |
0.015 |
|
A16-1000 |
16 |
40 |
10.00 |
17.00 |
3.60 |
50.00 |
6.0 |
0.003 |
0.0071 |
0.012 |
|
A16-1100 |
16 |
40 |
11.00 |
18.70 |
3.70 |
55.00 |
7.0 |
0.003 |
0.0062 |
0.010 |
|
A16-1200 |
16 |
40 |
12.00 |
20.40 |
4.20 |
60.00 |
7.5 |
0.002 |
0.0060 |
0.009 |
|
A16-1300 |
16 |
40 |
13.00 |
23.00 |
4.40 |
65.00 |
8.5 |
0.002 |
0.0060 |
0.009 |
|
A16-1400 |
16 |
100 |
14.00 |
23.80 |
4.60 |
70.00 |
9.0 |
0.002 |
0.0045 |
0.008 |
