Number |
I hold (A) |
I trip (A) |
RESISTANCE (Ω) | TIME TO TRIP(s)@ 1A |
OPERATING TEMPERATURE (°C) |
||||
| R MIN | R MAX | R1 MAX | TYP | MAX | MIN | MAX | |||
| TRF600-110 | 0.110 | 0.2200 | 8.0 | 12.0 | 19.0 | 1.4 | 4.0 | -40 | 85 |
| TRF600-150 | 0.150 | 0.3000 | 6.0 | 12.0 | 22.0 | 5.0 | 8.0 | -40 | 85 |
| TRF600-160 | 0.160 | 0.320 | 4.0 | 10.0 | 18.0 | 7.5 | 18.0 | -40 | 85 |
