Number |
I hold (A) |
I trip (A) |
RESISTANCE (Ω) | TIME TO TRIP(s)@ 1A |
OPERATING TEMPERATURE (°C) |
||||
| R MIN | R MAX | R1 MAX | TYP | MAX | MIN | MAX | |||
| TRF250-080 | 0.08 | 0.160 | 15 | 22 | 33 | -40 | 85 | ||
| TRF250-090 | 0.09 | 0.180 | 15 | 22 | 33 | -40 | 85 | ||
| TRF250-110 | 0.11 | 0.220 | 5.0 | 9.0 | 16.0 | 0.75 | 1.20 | -40 | 85 |
| TRF250-120 | 0.120 | 0.240 | 4.0 | 8.0 | 16.0 | 1.5 | 2.5 | -40 | 85 |
| TRF250-145 | 0.145 | 0.290 | 3.0 | 6.0 | 14.0 | 2.50 | 5.0 | -40 | 85 |
| TFR250-180 | 0.180 | 0.65 | 0.8 | 2.2 | 4.0 | 0.5 | 2.0 | -40 | 85 |
| TRF250-400 | 0.40 | 0.80 | 0.750 | 1.1 | 3 | 0.5 | 2.0 | -40 | 85 |
| TRF250-500 | 0.50 | 1.00 | 0.750 | 1.1 | 3 | 0.5 | 2.0 | -40 | 85 |
| TRF250-1000 | 1.0 | 2.0 | 0.22 | 0.33 | 0.58 | 5 | 21 | -40 | 85 |
