Number |
HOLD CURRENT (A) |
TRIP CURRENT (A) |
RESISTANCE (Ω) |
TIME TO TRIP(SEC) @ 0.25 A |
POST-TRIP RESISTANCE (Ω) |
TRIPPED-STATE POWER DISSIPATION @ 265 V (W) |
||
| R MIN | R MAX | MAX | MAX | NOM | MAX | |||
| LVR005 | 0.05 | 0.12 | 18.5 | 31.0 | 10.0 | 65.0 | 0.9 | 1.1 |
| LVR008 | 0.08 | 0.19 | 7.4 | 12.0 | 0.8 | |||
| LVR012 | 0.12 | 0.30 | 3.0 | 6.5 | 15.0 | 12.0 | 1.0 | |
| LVR016 | 0.16 | 0.37 | 2.5 | 4.1 | 15.0 | 7.8 | 1.4 | |
| LVR025 | 0.25 | 0.56 | 1.3 | 2.1 | 18.5 | 3.8 | 1.5 | |
| LVR033 | 0.33 | 0.74 | 0.77 | 1.24 | 21.0 | 2.6 | 1.7 | |
| LVR040 | 0.40 | 0.90 | 0.6 | 0.97 | 24.0 | 1.9 | 2.0 | |
| LVR055 | 0.55 | 1.25 | 0.45 | 0.73 | 26.0 | 1.45 | 3.4 | |
| LVR075 | 0.75 | 1.5 | 0.316 | 0.483 | 18.0 | 0.839 | 2.55 | |
| LVR100 | 1.0 | 2.0 | 0.218 | 0.334 | 21.0 | 0.580 | 2.87 | |
| LVR125 | 1.25 | 2.50 | 0.117 | 0.179 | 18.0 | 0.32 | 2.0 | |
