Part
Number |
集电通
JDT |
IH
(A) |
IT
(A) |
VMAX
(VDC) (VAC RMS) |
IMAX
(DCADC) (ACARMS) |
PD TYP
(W) |
Max Time
-to-trip (A) (S) |
RMIN
(Ω) |
RMAX
(Ω) |
R1MAX
(Ω) |
Lead Size
[mm2(AWG)] |
|
RHEF050
|
A30-050
|
0.5
|
0.9
|
30 ——
|
40 ——
|
0.9
|
2.5 2.5
|
0.480
|
0.780
|
1.10
|
[0.205mm2(24)]
|
|
RHEF070
|
——
|
0.7
|
1.4
|
30 ——
|
40 ——
|
1.4
|
3.5 3.2
|
0.300
|
0.540
|
0.80
|
[0.205mm2(24)]
|
|
RHEF100
|
——
|
1.0
|
1.8
|
30 ——
|
40 ——
|
1.4
|
5.0 5.2
|
0.180
|
0.300
|
0.43
|
[0.205mm2(24)]
|
|
RUEF090
|
A30-090
|
0.90
|
1.80
|
30 30
|
100 70
|
0.6
|
4.50 5.9
|
0.070
|
0.120
|
0.22
|
[0.205mm2(24)]
|
|
RUEF110
|
A30-110
|
1.10
|
2.20
|
30 30
|
100 70
|
0.70
|
5.50 6.6
|
0.070
|
0.100
|
0.17
|
[0.205mm2(24)]
|
|
RUEF135
|
A30-135
|
1.35
|
2.70
|
30 30
|
100 70
|
0.80
|
6.75 7.3
|
0.040
|
0.080
|
0.13
|
[0.205mm2(24)]
|
|
RUEF160
|
A30-160
|
1.60
|
3.20
|
30 30
|
100 70
|
0.90
|
8.00 8.0
|
0.030
|
0.070
|
0.11
|
[0.205mm2(24)]
|
|
RUEF185
|
A30-185
|
1.85
|
3.70
|
30 30
|
100 70
|
1.00
|
9.25 8.7
|
0.030
|
0.060
|
0.09
|
[0.205mm2(24)]
|
|
RUEF250
|
A30-250
|
2.50
|
5.00
|
30 30
|
100 70
|
1.20
|
12.50 10.3
|
0.020
|
0.040
|
0.07
|
[0.205mm2(24)]
|
|
RUEF300
|
A30-300
|
3.00
|
6.00
|
30 30
|
100 70
|
2.00
|
15.00 10.8
|
0.020
|
0.050
|
0.08
|
[0.520mm2(20)]
|
|
RUEF400
|
A30-400
|
4.00
|
8.00
|
30 30
|
100 70
|
2.50
|
20.00 12.7
|
0.010
|
0.030
|
0.05
|
[0.520mm2(20)]
|
|
RUEF500
|
A30-500
|
5.00
|
10.00
|
30 30
|
100 70
|
3.00
|
25.00 14.5
|
0.010
|
0.030
|
0.05
|
[0.520mm2(20)]
|
|
RUEF600
|
A30-600
|
6.00
|
12.00
|
30 30
|
100 70
|
3.50
|
30.00 16.0
|
0.005
|
0.020
|
0.04
|
[0.520mm2(20)]
|
|
RUEF700
|
A30-700
|
7.00
|
14.00
|
30 30
|
100 70
|
3.80
|
35.00 17.5
|
0.005
|
0.020
|
0.03
|
[0.520mm2(20)]
|
|
RUEF800
|
A30-800
|
8.00
|
16.00
|
30 30
|
100 70
|
4.00
|
40.00 18.8
|
0.005
|
0.013
|
0.02
|
[0.520mm2(20)]
|
|
RUEF900
|
A30-900
|
9.00
|
18.00
|
30 30
|
100 70
|
4.20
|
45.00 20.0
|
0.005
|
0.010
|
0.02
|
[0.520mm2(20)]
|
